TREK DOMANE SLR 9 2025

Frame
OCLV Carbon Series 800 with IsoSpeed, internal storage compartment, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat-mount disc brakes, 142x12 mm thru axle.

Frame-Fork Set
OCLV Carbon Series 800, IsoSpeed, internal storage compartment, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat-mount disc brakes, 142x12 mm thru axle.

Fork
Domane SLR carbon, tapered carbon steerer, internal brake cable routing, fender mounts, flat-mount disc brakes, carbon dropouts, 12x100 mm thru axle.

Frame Fit
Endurance

Weight
56 - 7.25 kg (with TLR sealant, without inner tubes)

Maximum Weight Limit
Total weight limit (including bike, rider, and cargo): 125 kg.

Battery
Shimano BT-DN300

Charger
Recharge cable included

Shifter
Shimano Dura-Ace R9270 Di2, 12-speed

Front Derailleur
Shimano Dura-Ace R9250 Di2, braze-on, down swing

Rear Derailleur
Shimano Dura-Ace R9250 Di2, max 34T cog

Crankset

• Size 47, 50: Shimano Dura-Ace R9200, 50/34, 165 mm length
• Size 52, 54: Shimano Dura-Ace R9200, 50/34, 170 mm length
• Size 56, 58: Shimano Dura-Ace R9200, 50/34, 172.5 mm length
• Size 60, 62: Shimano Dura-Ace R9200, 50/34, 175 mm length

Bottom Bracket
Praxis, T47 threaded, internal bearing

Cassette
Shimano Dura-Ace R9200, 11-34, 12-speed

Chain
Shimano Dura-Ace/XTR M9100, 12-speed

Max Chainring Size
1x: 48T, 2x: 52/36

Wheels

• Front: Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 100x12 mm thru axle
• Rear: Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 142x12 mm thru axle

Wheel Skewers
Bontrager Switch thru axle with removable lever (front and rear)

Tires
Bontrager R3 Hard-Case Lite, tubeless-ready, aramid bead, 120 TPI, 700x32 mm

Tire Accessories
Bontrager TLR sealant, 177 ml

Rim Strips
Bontrager TLR

Max Tire Size
38 mm without fenders, 35 mm with fenders

Saddle

• Size 47, 50, 52: Verse Short Pro, carbon rails, 155 mm width
• Size 54, 56, 58, 60, 62: Verse Short Pro, carbon rails, 145 mm width

Seatpost

• Sizes 47, 50, 52, 54, 56: KVF carbon aero, 20 mm offset, 280 mm length
• Sizes 58, 60, 62: KVF carbon aero, 20 mm offset, 320 mm length

Handlebar

• Size 47: Bontrager Pro IsoCore VR-SF, 38 cm width
• Sizes 50, 52: Bontrager Pro IsoCore VR-SF, 40 cm width
• Sizes 54, 56: Bontrager Pro IsoCore VR-SF, 42 cm width
• Sizes 58, 60, 62: Bontrager Pro IsoCore VR-SF, 44 cm width

Handlebar Tape
Bontrager Supertack Perf

Stem

• Size 47: Trek RCS Pro, -7°, 70 mm length
• Size 50: Trek RCS Pro, -7°, 80 mm length
• Sizes 52, 54: Trek RCS Pro, -7°, 90 mm length
• Sizes 56, 58: Trek RCS Pro, -7°, 100 mm length
• Sizes 60, 62: Trek RCS Pro, -7°, 110 mm length

Brakes
Shimano Dura-Ace hydraulic disc

Brake Rotors

• Sizes 47 to 62: Shimano CL900, centerlock, 160 mm
• Sizes 47 to 62: Shimano MT900, centerlock, 160 mm

Brake Rotor Size Limit
Maximum rotor size: 160 mm (front and rear)

Storage Bag
Bontrager frame-integrated storage compartment BITS
