TREK MADONE SL 6 2025

Frame:

• Material: OCLV Carbon Series 500
• Shape: Full System Foil
• Seat Tube: IsoFlow
• Headset: RCS
• Compatibility: Electronic or mechanical routing
• Additional Features: Removable aerodynamic chain guide, T47 bottom bracket, Flat Mount disc brakes, universal derailleur hanger (UDH), 142x12 mm thru-axle

Fork:

• Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100 mm chamfered thru axle

Weight:

• Size ML : 8.16 kg (17.99 lbs) with TLR sealant, tubeless setup

Maximum Weight:

• 125 kg (including bike, rider, and luggage)

Charger:

• Recharge cable included

Drivetrain:

• Shifters: Shimano 105 R7170, 12-speed
• Front Derailleur: Shimano 105 R7150 Di2, braze-on, down swing
• Rear Derailleur: Shimano 105 R7150 Di2, max cog 36 teeth
• Crankset:
  • Size XS, S: Shimano 105 R7100, 50/34, 165 mm crank length
  • Size M: Shimano 105 R7100, 50/34, 170 mm crank length
  • Size ML, L: Shimano 105 R7100, 50/34, 172.5 mm crank length
  • Size XL: Shimano 105 R7100, 50/34, 175 mm crank length
• Bottom Bracket: Praxis, T47 threaded, internal bearing
• Cassette: Shimano 105 7101, 11-34, 12-speed
• Chain: Shimano SLX M7100, 12-speed

Wheels:

• Front Wheel: Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth, 100x12 mm thru axle
• Rear Wheel: Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth, Shimano 11/12-speed freehub body, 142x12 mm thru axle
• Thru Axles (front/rear): Bontrager Switch, chamfered thru axle, removable lever
• Tires: Bontrager R3 Hard-Case Lite, tubeless-ready, aramid bead, 170 tpi, 700x28 mm
• Sealant: Bontrager TLR, 177 ml
• Rim Tape: Bontrager TLR
• Max Tire Size: 32 mm

Saddle and Seatpost:

• Saddle:
  • Size XS, S: Bontrager Aeolus Comp, steel rails, 155 mm width
  • Size M, ML, L, XL: Bontrager Aeolus Comp, steel rails, 145 mm width
• Seatpost:
  • Size XS, S, M, XL: Madone aero, 0 mm offset, short length
  • Size ML, L: Madone aero, 0 mm offset, long length

Handlebar and Stem:

• Handlebar: Bontrager Comp, alloy, 31.8 mm
  • Size XS: 36 cm width (drops 40 cm), 80 mm reach, 121 mm height
  • Size S, M: 38 cm width (drops 42 cm), 80 mm reach, 121 mm height
  • Size ML, L: 40 cm width (drops 44 cm), 80 mm reach, 121 mm height
  • Size XL: 42 cm width (drops 46 cm), 80 mm reach, 121 mm height
• Stem:
  • Size XS: Trek RCS Pro, -7°, 80 mm length
  • Size S, M: Trek RCS Pro, -7°, 90 mm length
  • Size ML, L: Trek RCS Pro, -7°, 100 mm length
  • Size XL: Trek RCS Pro, -7°, 110 mm length

Brakes:

• Rotors: Shimano RT70, centerlock, 160 mm
• Max Rotor Size: 180 mm front, 160 mm rear
